ST104A-HB

Product Features

◆1U  Hot-swappable Chassis ,Support 12 * 13 down compatible motherboard.
◆Supports four hot-swappable 3.5-inch hard disk (Universal 2.5-inch).Support 9.5mm slim CD-ROM (by conversion bracket into 2.5 SSD drive bays, a standard 1U power bit..
◆Using shockproof 4 * 4028 + 2 * 4056 wind wall, wind round after round ducting.
Product Detail Compatible Download >>



Specification

Order Code
ST104A-HB
Description
1U four hot-swap
M/B Form Factor
EEB (12"X13")
Processor
Supports dual intel/AMD processors
Support Backplane
6GB/s SATA SAS
Front bezel
Option
Chassis Dimension
D x W x H (mm) 655 x 440 x 44 (mm)
D x W x H (inch) 25.79" x 17.32" x 1.73"
Power Supply
Form Factor 1U
Drive Bay
3.5" or 2.5" HDD; 4（MAX=4）
Slim CD-ROM 1
Generality
Metal Material SGCC/SECC(Option)
Metal Thickness 1.0mm+1.2mm
Plastic Material Type ABS
Expansion Slots
Cross card 1
System Cooling
Middle Standard 2 * 4056 + 4 * 4028 ball fan
I/O Gasket
Removable
Slide Rails
Option
Front Panel
Front Control Power On/Off
System Reset
Indicator Power LED*1
HDD Activity LED*1
LAN Activity LED*2
System warning LED*1
Ports USB Ports*1
Shipping Information*
Net Weight
(Chassis Only)		 7.7kg
Gross Weight (w/Packing) 11kg
Cubic Feet 770*585*162 mm
Container Information
20' 444 Box
40' 920 Box
40'H 1027 Box



Standard Packing List

Part Category Qty Description
Chassis 1 1U chassis base
HDD Trays 4 For 3.5"or 3.5" HDD
Cables 1 Power On/Off  System Reset
PCB 1 HDD Backplane
Fans 6 2*4056+4*4028 ball fan
I/O Gasket 1 I/O Gasket
Expansion Slots 1 Cross card



Optional Accessory



I/O Gasket

Product Part No. Description
ST-IO01

Be applicable to：Intel S5000PSL/VSA/XVN
ST-IO02 Be applicable to： Intel S5520HC/S5500BC/S3420GP
ST-IO03 Be applicable to：INTEL S2400GP/S2600CP
ST-IO04 Be applicable to：Supermicro X8 series server board
ST-IO05 Be applicable to：Supermicro X9 series server board
ST-IO06 Be applicable to：TYAN S7001
ST-IO07 Be applicable to：ASUS Z8
ST-IO08 Be applicable to：ASUS Z9NA
ST-IO09 Be applicable to：ASUS Z9PE



CPU Air Duct

Product Part No. Description
  ST-DFC05 Be applicable to：SUPERMICRO X9DRI
  ST-DFC07 Be applicable to：INTEL S2400GP



Power

Product Part No. Description
SS-400H1U SeaSonic 1U 400W，SS-400H1U Active PFC 80+
SS-460H1U SeaSonic 1U 460W，SS-460H1U Active PFC 80+



Front bezel

Product Part No. Description
STCMB-1U

Dedicated to ST104A/B/C Series 1U chassis



Riser Card

Product Part No. Description
ST18X-E PCI-E X8、Dedicated to ST104A/B/C Series 1U chassis
ST116X-E PCI-E X16、Dedicated to ST104A/B/C Series 1U chassis

Slide Rails

Product Part No. Description
ST104 Standard 1U machine rail，
ST104-LX

Blue zinc plated strengthen type 1U machine rail.
