ST104C-HB

Product Features

◆1U  Hot-swappable Chassis ,Support  6.75*6.75 down compatible motherboard.
◆Supports four hot-swappable 3.5-inch hard disk (Universal 2.5-inch).Support 9.5mm slim CD-ROM (by conversion bracket into 2.5 SSD drive bays, a standard 1U FLEX power bit..
◆Using shockproof  6 * 4028 wind wall, wind round after round ducting.
Product Detail Compatible Download >>

Specification

Order Code
ST104C-HB
Description
1U four hot-swap
M/B Form Factor
6.75X6.75（17.15CMX17.15CM）
Processor
Supports dual intel/AMD processors
Support Backplane
6GB/s SATA SAS
Front bezel
Option
Chassis Dimension
D x W x H (mm) 450 x 440 x 44 (mm)
D x W x H (inch) 17.72" x 17.32" x 1.73"
Power Supply
Form Factor 1U FLEX
Drive Bay
3.5" or 2.5" HDD; 4（MAX=4）
Slim CD-ROM 1
Generality
Metal Material SGCC/SECC(Option)
Metal Thickness 1.0mm+1.2mm
Plastic Material Type ABS
Expansion Slots
Cross card 1
System Cooling
Middle Standard 6 * 4028 ball fan
I/O Gasket
Removable
Slide Rails
Option
Front Panel
Front Control Power On/Off System Reset
Indicator Power LED*1
HDD Activity LED*1
LAN Activity LED*2
System warning LED*1
Ports USB Ports*1
Shipping Information*
Net Weight (Chassis Only) 6.06kg
Gross Weight (w/Packing) 8.02kg
Cubic Feet 585*570*162 mm
Container Information
20' 596 Box
40' 1224 Box
40'H 1392 Box



Standard Packing List

Part Category Qty Description
Chassis 1 1U chassis base
HDD Trays 4 For 3.5"or 2.5" HDD
Cables 1 Power On/Off System Reset
PCB 1 HDD Backplane
Fans 6 6*4028 ball fan
I/O Gasket 1 I/O Gasket
Expansion Slots 1 Cross card



Optional Accessory
